In the scheme design, fully consider the bean residue moisture content, high protein content, viscous characteristics, and adopt a series of supporting technology and process to solve, in order to ensure good drying effect, can use gas, biomass, biogas, gas, steam and other new clean heat source.
Excellent structure, simple, material through the cylinder resistance running smoothly, easy to operate.
A special dispersing device is used to ensure sufficient mass and heat exchange of materials.
Professional team tailor-made for you, after drying section can be matched with grinding, mixing, granulation, packaging and other subsequent sections, to produce bean slag pellet feed finished products.
Product drying uniformity is good, can realize mechanized control, can run continuously.
| model （m） | Drum diameter(mm) | Drum length(m) | gradient (º ) | rotate speed (r/min) | weight (t) | rate of work (kw) | cubage (m3) |
|---|---|---|---|---|---|---|---|
| Ф0.8×10 | Ф800 | 10 | 3-5 | 7.2 | 6.9 | 4 | 5.02 |
| Ф1.0×10 | Ф1000 | 10 | 3-5 | 6.73 | 7.5 | 5.5 | 7.85 |
| Ф1.2×12 | Ф1200 | 12 | 3-5 | 5.8 | 13.1 | 11 | 13.31 |
| Ф1.5×12 | Ф1500 | 12 | 3-5 | 4.8 | 22.3 | 15 | 21.2 |
| Ф1.8×14 | Ф1800 | 14 | 3-5 | 3.2 | 45.8 | 30 | 48.22 |
| Ф2.2×18 | Ф2200 | 18 | 3-5 | 3 | 50.3 | 37 | 70.43 |
| Ф2.4×20 | Ф2400 | 20 | 3-5 | 2.83 | 78.4 | 45 | 90.43 |
| Ф2.8×24 | Ф2800 | 24 | 3-5 | 2.59 | 97 | 75 | 147.8 |
| Ф3.0×20 | Ф3000 | 20 | 3-5 | 2.6 | 102 | 55 | 141.3 |
| Ф3.0×25 | Ф3000 | 25 | 3-5 | 2.6 | 110 | 75 | 176.7 |
| Ф3.2×25 | Ф3200 | 25 | 3-5 | 2.5 | 110 | 90 | 201 |
| Ф3.6×28 | Ф3600 | 28 | 3-5 | 2.3 | 135 | 160 | 284.9 |
