The structure is simple, the failure rate is reduced, the stone powder loss is less during the sand washing process, and the sand grading and fineness modulus meet the standard requirements. High cleaning degree, large processing capacity, stable operation, low power consumption and long service life, suitable for a variety of working environments.
Less wearing parts greatly reduce the cost of equipment, needn't to increase the screen, prolong the service life of the equipment.
The whole process is fully automatic, without labor, can save a lot of labor costs in the process of sewage treatment.
High working frequency, high vibration intensity, low moisture on the screen, high unit processing capacity, can work continuously for 24 hours.
Reasonable structure, occupy a small area, simple installation, low investment cost, long service life, low maintenance cost.
| Specification | Centre drive | Edge drive | ||||
| Model | GXZ1542 | GXZ1842 | GXZ2042 | GXB2066 | GXB2266 | GXB2566 |
| Feed size（mm） | ＜60 | ＜80 | ＜90 | ＜90 | ＜100 | ＜120 |
| Rotate speed（r/min） | 11-13 | 10-12 | 9-11 | 9-12 | 8-10 | 6-8 |
| Power（kw） | 15 | 18.5 | 22 | 22 | 30 | 37 |
| Capacity（t/h） | 50-80 | 80-100 | 100-150 | 120-160 | 150-200 | 200-250 |
| Overall dimension（mm） | 6705x1738 x2180 | 6705x1938 x2200 | 6705x2138 x2220 | 6600x4400 x2565 | 6600x4600 x2765 | |
